Exhaust Fans · Industrial Ventilation
Gale Heavy Duty Exhaust Fan
Heavy-duty industrial ventilation · 300-600 mm sweep · Single & Three Phase options · Up to 9,500 m³/hr air delivery
Available Sizes
Key specifications
- Sweep
- 450 mm / 18"
- Speed
- 900 / 1400 RPM
- Power Input
- 240 / 450 W
- Air Delivery
- 3,900 / 9,500 m³/hr
Product Highlights
-
Heavy-Duty Totally Enclosed Motor: Designed with a totally enclosed motor construction for dependable operation in demanding industrial ventilation applications.
-
High Air Delivery: Available configurations deliver up to 9,500 m³/hr, supporting effective extraction of hot and stale air from larger working spaces.
Need Gale fans for a factory, project or bulk requirement? Share the required size, phase and quantity with our team.
Features
Gale combines robust motor construction, high air delivery and multiple electrical configurations for industrial exhaust and ventilation requirements.
- Heavy-Duty Totally Enclosed Motor
- Aluminium Motor Body with Fins
- Capacitor Start & Run Induction Motor
- Copper Winding
Technical Specifications
Gale Heavy Duty Exhaust Fan performance.
| Size | Supply | Speed | Input Current | Power Input | Air Delivery | Size A | Size B |
|---|---|---|---|---|---|---|---|
| 300 mm / 12" | Single Phase, 50 Hz | 900 / 1400 RPM | 0.25 / 0.40 A | 90 / 170 W | 1,700 / 4,150 m³/hr | 395 mm | 305 mm |
| 380 mm / 15" | Single Phase, 50 Hz | 900 / 1400 RPM | 0.45 / 0.75 A | 160 / 270 W | 2,700 / 7,600 m³/hr | 483 mm | 375 mm |
| 450 mm / 18" | Single Phase, 50 Hz | 900 / 1400 RPM | 0.65 / 1.20 A | 240 / 450 W | 3,900 / 9,500 m³/hr | 560 mm | 450 mm |
| 600 mm / 24" | Single Phase, 50 Hz | 900 RPM | 2.50 A | 460 W | 9,400 m³/hr | 723 mm | 593 mm |
| 300 mm / 12" | Three Phase, 50 Hz | 1400 RPM | 0.50 A | 90 W | 1,710 m³/hr | 395 mm | 305 mm |
| 380 mm / 15" | Three Phase, 50 Hz | 1400 RPM | 0.35 A | 170 W | 4,200 m³/hr | 483 mm | 475 mm |
| 450 mm / 18" | Three Phase, 50 Hz | 1400 RPM | 0.85 A | 240 W | 6,120 m³/hr | 560 mm | 450 mm |
| 600 mm / 24" | Three Phase, 50 Hz | 900 RPM | 1.50 A | 460 W | 9,400 m³/hr | 723 mm | 593 mm |
Performance varies by sweep size, speed and electrical configuration. Confirm the required model while placing your enquiry.
Download full spec sheet (PDF · 480 KB)Configurations
Also Available
Additional configurations are available for specific industrial, project and export requirements.
-
60 Hz Configurations
-
Three Phase Export Voltages
-
CB Scheme Certified Model
-
Resettable Thermal Protection
-
Guard & Louvers
-
Reversible Configuration
Need a custom Gale requirement?
More about
Gale - Heavy-Duty Exhaust Ventilation for Industrial Spaces
The Gale Heavy Duty Exhaust Fan is designed for industrial environments that require dependable removal of hot, stale air and continuous movement of large volumes of air through a space.
Ideal Applications
Industrial Ventilation Where High Air Extraction Matters
-
Factories
Helps exhaust hot and stale air from manufacturing and production areas.
-
Workshops
Suitable for enclosed workspaces where heat builds up during regular operations.
-
Warehouses
Supports air exchange across storage and logistics environments.
-
Industrial Sheds
High-volume exhaust ventilation for large enclosed or semi-enclosed working spaces.
-
Production Areas
Helps improve air movement where machinery and operations generate heat.
-
Utility & Equipment Rooms
Suitable for general ventilation requirements in enclosed technical and equipment areas.
FAQ
Frequently Asked Questions
Common questions about Gale Heavy Duty Exhaust Fan, available configurations, and industrial applications. Don't see yours? Talk to our team.
What sizes are available in the Gale Heavy Duty Exhaust Fan?
Gale is available in 300 mm, 380 mm, 450 mm and 600 mm sizes.
Is Gale available in Single Phase and Three Phase?
Yes. AVM publishes both Single Phase and Three Phase configurations across the Gale range.
What is the maximum air delivery of Gale?
The highest published air delivery is 9,500 m³/hr for the 450 mm Single Phase configuration at the corresponding published operating point. The 600 mm models are listed at 9,400 m³/hr.
Does Gale use a totally enclosed motor?
Yes. AVM specifies a heavy-duty totally enclosed motor with a finned aluminium motor body.
Does Gale use copper winding?
Yes. Copper winding is specified across the Gale product features.
Are 60 Hz Gale models available?
Yes. AVM lists 110 V Single Phase 60 Hz and 380/400/440 V 60 Hz configurations among the available options.
Can Gale be supplied with louvers?
Yes. A fan configuration with guard and louvers is listed as available.
Is a reversible Gale fan available?
Yes. AVM lists reversible operation through an alternative blade-mounting configuration.
Built for Serious Industrial Ventilation
Enquire About the Gale Heavy Duty Exhaust Fan
Tell us your required sweep size, phase, application and quantity. The AVM team will assist with the appropriate Gale configuration and quotation.
