Pedestal Fans · Industrial
Enlil Air Circulator Pedestal Fan
Heavy-duty air circulation · 450-750 mm sweep · Up to 22,200 m³/hr air delivery · Single & Three Phase options
Available Sizes
Key specifications
- Sweep
- 450 mm
- Air Delivery
- 7,500 m³/hr
- Power Input
- 100 W
- Phase
- Single Phase
Product Highlights
-
Powerful Air Delivery: Delivers 7,500 m³/hr of air with the 450 mm model for effective circulation across industrial and commercial spaces.
-
Heavy-Duty Induction Motor: Capacitor start and run induction motor designed for dependable performance in demanding applications.
Need bulk quantities or a specific configuration? Share your requirement with our team.
Features
The Enlil combines a heavy-duty motor, durable construction and flexible air-direction control for industrial and commercial environments.
- Capacitor Start & Run Induction Motor
- 100% Copper Winding
- Class F Insulation - 155°C
- Sealed Double Ball Bearings with P6 Tolerance
Technical Specifications
Available in multiple sweep sizes and phase configurations to suit different industrial air-circulation requirements.
| Size / Sweep | Phase | Speed | Current | Power Input | Air Delivery | Peak Air Velocity | Max. Height | Min. Height | Noise Level |
|---|---|---|---|---|---|---|---|---|---|
| 450 mm (18") | Single | 1440 RPM | 0.45 A | 100 W | 7,500 m³/hr | 250 m/min | 1.00 m | 0.85 m | 64 dBA |
| 600 mm (24") | Single | 1440 RPM | 0.70 A | 150 W | 15,000 m³/hr | 250 m/min | 1.40 m | 1.30 m | 68 dBA |
| 750 mm (30") | Single | 1440 RPM | 1.15 A | 250 W | 22,200 m³/hr | 250 m/min | 1.50 m | 1.30 m | 74 dBA |
| 600 mm (24") | Three | 1440 RPM | 0.40 A | 200 W | 15,000 m³/hr | 250 m/min | 1.40 m | 1.30 m | 68 dBA |
| 750 mm (30") | Three | 1440 RPM | 0.55 A | 250 W | 22,200 m³/hr | 250 m/min | 1.50 m | 1.30 m | 74 dBA |
Specifications may vary by configuration. Confirm voltage, frequency and model requirements while placing your enquiry.
Download full spec sheet (PDF · 480 KB)Configurations
Also Available
Configurations available for bulk, OEM and export orders.
-
Power Saver model
-
Finger-proof guard
-
110V / 220V, 60 Hz models
-
Customised colour combinations for MOQ orders
-
Motor with inbuilt resettable thermal protector
-
450, 600 and 750 mm models in 900 RPM
-
Fully enclosed motor for dusty environments and poultry farms
-
IEC 60335-1 & 2 CB Scheme certified model
Need a configuration not listed?
More about
Enlil Industrial Air Circulator Fan - Built for Demanding Spaces
The Enlil Air Circulator Pedestal Fan is designed for powerful air movement across factories, warehouses, workshops, production areas and other large commercial or industrial spaces. Its high-speed motor and aerodynamic aluminium blades create strong, focused airflow that helps improve air circulation across wide working areas.
Ideal Applications
Powerful Air Circulation Across Industrial and Commercial Spaces
-
Factories
Helps circulate air across production floors, assembly areas and manufacturing environments.
-
Warehouses
Moves large volumes of air across storage areas, distribution centres and logistics facilities.
-
Workshops
Provides strong directional airflow around machinery, workstations and large working areas.
-
Industrial Sheds
Suitable for open and semi-open industrial environments requiring high-volume air circulation.
-
Gyms & Sports Facilities
Supports effective air movement across large, high-occupancy activity spaces.
-
Poultry & Agricultural Facilities
A fully enclosed motor configuration is available for dusty environments such as poultry farms.
FAQ
Frequently Asked Questions
Common questions about Enlil Air Circulator Pedestal Fan, available configurations, and industrial applications. Don't see yours? Talk to our team.
What sizes are available in the Enlil Air Circulator Pedestal Fan?
The Enlil is available in 450 mm (18"), 600 mm (24") and 750 mm (30") sweep sizes. Single-phase models are available across all three sizes, while 600 mm and 750 mm models are also available in three-phase configurations.
What is the air delivery of the Enlil Air Circulator Fan?
Air delivery depends on the sweep size. The 450 mm model delivers 7,500 m³/hr, the 600 mm model delivers 15,000 m³/hr and the 750 mm model delivers up to 22,200 m³/hr.
Is the Enlil suitable for factories and warehouses?
Yes. The Enlil is designed for high-volume air circulation in large industrial and commercial spaces such as factories, warehouses, workshops, production areas and industrial sheds.
Can the Enlil be used in dusty environments?
A fully enclosed motor configuration is available specifically for dusty operating environments and applications such as poultry farms. Share the operating conditions with AVM while enquiring so the appropriate configuration can be recommended.
Does the Enlil Air Circulator oscillate?
Yes. The fan offers up to 85° oscillation along with an indexing mechanism up to 360°, allowing the direction and coverage of airflow to be adjusted according to the space.
Are special voltage and export configurations available?
Yes. 110V and 220V 60 Hz models are available for specific requirements. An IEC 60335-1 & 2 CB Scheme certified model is also available for applicable export requirements.
Ready to order?
Enquire About the Enlil Industrial Air Circulator Fan
Tell us the required sweep size, quantity, installation environment and electrical configuration. Our team will help you identify the appropriate Enlil model and provide pricing for your requirement.
